Brochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 Heads

  • 1
  • 2
  • 3

Place of Origin : GuangDong, China

Brand Name : CWH

Model Number : DQB-404

Certification : CE

Supply Ability : 20 Set/Sets per Month

Packaging Details : export standard packing

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, T/T

Product Type : Paper Stape

Processing Type : Binding Machine

Power(W) : 0.75 KW

Condition : New

Voltage : 220V

Dimension(L*W*H) : 2200*1320*1350mm

Weight : 480 KG

Warranty : 12 month

After-sales Service Provided : Engineers available to service machinery overseas

Port : shen zhen port

Contact Now

 Saddle Stitch Binding Machine



Description:
Semi-Autometic Saddle Stitching Machine is a kind of special stapler used to stitching brochures
pictorials and magazines,  it adopts a style of SaddleStitching with iron wire. It is usually stitched with two
mechanic stitching. Four  mechanic stitching ones can work together. Any one can be chosen at will
six -mechanic stitching should be worked separately
This machine can send books stitch and collect books after putting in the pages by manual work. The whole

process is controlled by electric wire.  So it is stable and safe while whirling.






Technical Parameters:
Model             DQB404-04C   CWH604
Biding Size   89*127~305*450mm 590~305mm
Max . Binding Thickness 4mm   0.2~4mm
Stitching Speed   15~70times/min   30~70times/min
Width of Staple Boot   13mm   13mm
Distance of Center of Staple Boot 45~270mm   45~270mm
Use of Steel Wire   25#-26#   25#-26#
Main Motor   380v.50Hz 0.55kw 220V 0.75kw
Weight of Machine   420kg   480kg
Dimension   2200*1320*1350mm 2200*1320*1350mm



Brochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 HeadsBrochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 HeadsBrochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 HeadsBrochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 HeadsBrochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 HeadsBrochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 HeadsBrochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 HeadsBrochure Folding Stitching Machine Saddle Stitch Binding Machine Up To 4 Heads
